Product introduction



MDSC311E series current isolator (output) Mounted as a guide rail, the base and the host can be separated from the plug, easy installation and maintenance. Series of products rich, can handle the current, voltage, thermal resistance, thermocouple, switch and other industrial products are widely signal. The application in building material, metallurgy, electric power and other industries, effectively restrain all kinds of interference signal.





function

Receive Control Room 4~20mA The current signal, after isolation, converted into voltage or current signal output to the user specified, the scene. Optional One enter One A, One enter Two A, Two enter Two A.

Type specification

Product model	1 input signal	2 input signal	The 1 output signal	The 2 output signal
MDSC311E-C0C0	4~20mADC	No input 2	4~20mADC	Output 2
MDSC311E-C0CC	4~20mADC	No input 2	4~20mADC	4~20mADC
MDSC311E-CCCC	4~20mADC	4~20mADC	4~20mADC	4~20mADC







Product features:

The input and output power, the three party is completely isolated, strong anti-interference ability

High precision, high linearity, high stability

Modular design, small volume, low power consumption, suitable for intensive installation

Reasonable structure, easy plugging, installation, disassembly and maintenance is more convenient and simple

Technical indicators

The working power supply: 24VDC . 10%

Work    Consumption: less than or equal to 0.8W ( One enter One A)

Less than or equal to 1.6W ( One enter Two A)

Less than or equal to 2.0W ( Two enter Two A)

Input signal: 4~20mA

Input impedance: less than or equal to Two hundred Omega

Output signal: 4~20mA

Output load: 0~650 Omega

Conversion accuracy: + 0.1%F.S

Temperature drift:. 0.01% F.S/ C

Dielectric strength: input / The output is more than 2000VAC ( 1min )

output / The power is greater than or equal to 2000VAC ( 1min )

          input / The power is greater than or equal to 1000VAC ( 1min )

Insulation resistance: input / output / The power is greater than or equal to 100M (omega 500VDC )

Remarks： One enter One A model, One , Three , Eleven , Twelve Don't pick feet up; One enter Two A model, Eleven , TwelveDon't pick feet up.



For details please download:MDSC311E series currentisolator(output)
