MDSB302E series Isolated Safety gate Mounted as a guide rail, the base and the host can be separated from the plug, easy installation and maintenance. This series Safety gate A variety of products, can handle the current, voltage, thermal resistance, thermocouple, switch and other industrial products are widely signal. Used in chemical, petroleum, metallurgy, electric power, natural gas and other industries, connect with all kinds of this instrument, as the use of explosion-proof system and related equipment.
Products comply with " GB3836.1-2010 Explosive environment No. One Part: General requirements for equipment "and" GB3836.4-2010 Explosive environment No. Four Part: the intrinsic safety type" I "Protection equipment", through the China explosion-proof inspection agencies strict test qualified, And made explosion-proof certification.
function
This product is compatible with the distribution and isolation Two Modes: distribution mode, to a dangerous place Two WireTransmitter Supply, sampling Transmitter Output Two Wire current signal through the isolation after processing into Four Wire current isolation mode, sampling signal output; Four Wire current signal through the isolation output Four Wire current signal.The toggle switch product side built-in can set the input mode. Optional One enter One A, One enter Two A, Two enter Two A.Isolated gate From the terminal energy into the limit of intrinsically safe dangerous places, so as to ensure the safety and explosion-proof system.
Type specification
Product model | 1 input signal | 2 input signal | The 1 output signal | The 2 output signal |
MDSB302E-C0C0 | 4~20mADC | No input 2 | 4~20mADC | Output 2 |
MDSB302E-C0CC | 4~20mADC | No input 2 | 4~20mADC | 4~20mADC |
MDSB302E-CCCC | 4~20mADC | 4~20mADC | 4~20mADC | 4~20mADC |
Explosion-proof technology index
Explosion proof mark: [Exia Ga] II C
Authentication parameters: (terminal 4/6 Between, 1/3 Between)
Um=250V Uo=28V Io=93mA
Po =655mW Co=50nF Lo=2.4mH
Product features:
The input and output power, the three party is completely isolated, strong anti-interference ability
High precision, high linearity, high stability
Modular design, small volume, low power consumption, suitable for intensive installation
Reasonable structure, easy plugging, installation, disassembly and maintenance is more convenient and simple
Technical indicators
The working power supply: 24VDC . 10%
Work Consumption: less than or equal to 1.2W ( One enter One A)
Less than or equal to 1.8W ( One enter Two A)
Less than or equal to 2.4W ( Two enter Two A)
Input signal: danger zone
Distribution mode, Two Wire 4~20mA
Isolation mode, Four Wire 4~20mA
Voltage distribution: distribution mode, 16V@20mA
Distribution: the maximum short-circuit current protection, 40mA
The maximum open circuit voltage, 28V
Input impedance: isolation mode, less than or equal to Two hundred Omega
Output signal: Four Wire 4~20mA The safety zone,
Output load: 0~350 Omega
Conversion accuracy: + 0.1%F.S
Temperature drift:. 0.01% F.S/ C
Dielectric strength: input / The output is more than 2000VAC ( 1min )
input / The power is greater than or equal to 2000VAC ( 1min )
output / The power is greater than or equal to 1000VAC ( 1min )
Intrinsically safe / Non intrinsically safe, more than 2000VAC ( 1min )
Insulation resistance: input / output / The power is greater than or equal to 100M (omega 500VDC )
Remarks： One enter One A model, One , Three , Eleven , Twelve Don't pick feet up; One enter Two A model, One , Three Don't pick feet up.
The toggle switch is arranged near one side of the base, the input signal is Four Wire (isolation mode); on the contrary, for TwoWire (distribution mode).
Common specifications selection examples:
Model:MDSB302E-C0C0-1212
Input: 4-20mADC signal
Output1:4-20mADC signal
Aux.power:24VDC
Description: This product is a separateSafety gate, input :A road safety zone, 4-20mADC, output: danger zone, road 4-20mADC, power: DC24V
For details please download: MDSB302E series detection end distribution isolation Safety gate
