Function overview
MDSE105 series DC voltage Transmitter The DC voltage is detected in proportion to convert the DC voltage or current signal.
Specifications
DC voltage Transmitter | Input voltage code | Output signal code | The auxiliary power supply + function code |
MDSE105- | 6:0~120V | 1:0~5V | 13:DC24V |
7:0~250V | 2:1~5V | 33:AC220V |
8:0~300V | 3:0~20mA |
|
9:0~450V | 4:4~20mA |
|
0 other ranges: | 0 other ranges: |
|
Technical indicators
Input signal: Direct Voltage, see table
Input power: less than or equal to absorption 0.5VA (input 450V )
Less than or equal to 0.2VA (input 100V )
Input overload capacity: Two Times, continuous input voltage
Output signal: DC voltage or current, see table
Output: output voltage, load or load 5K Omega
The current output load is less than or equal to Five hundred and fifty Omega
Conversion accuracy: + 0.2%F.S
Response time: 10ms
Isolation mode: input, output, power supply isolated
Insulation resistance: 200M Omega /DC500V
Dielectric strength: input / output / Power Supply 2000VAC/1min
The auxiliary power supply: DC24V . 10% Less than or equal. 1W
AC86~265V Less than or equal. 3VA
For details please download:MDSE105 series DC voltageTransmitter
