Product introduction



MDSC309E series switch isolator (output) Mounted as a guide rail, the base and the host can be separated from the plug, easy installation and maintenance. Series of products rich, can handle the current, voltage, thermal resistance, thermocouple, switch and other industrial products are widely signal. The application in building material, metallurgy, electric power and other industries, effectively restrain all kinds of interference signal.





function

Receive control The switch signal room, isolation drive equipments, such as solenoid valves. Optional One enter One A, Two enterTwo A.



Type specification

Product model	1 input code	2 input code	The output of the 1 code	The output of the 2 code
MDSC309E-	1: passive switch	1: passive switch	1: passive relay	1: passive relay
	2: active switch	2: active switch	2: passive collector	2: passive collector
	G: other signals	G: other signals	4: active output	4: active output
		0: input 2	G: other signals	G: other signals
				0: output 2









Product features:

The input and output power, the three party is completely isolated, strong anti-interference ability

High precision, high linearity, high stability

Modular design, small volume, low power consumption, suitable for intensive installation

Reasonable structure, easy plugging, installation, disassembly and maintenance is more convenient and simple

Technical indicators

The working power supply: 24VDC . 10%

Work    Consumption: less than or equal to 2W ( Two enter Two (a) passive output)

Less than or equal to 3W ( Two enter Two (a) active output)

Input signal:

Passive switch input (contact):

Short circuit current: 8mA

The open circuit voltage: 8V

Active switch input:

Order negotiation technology index

Output signal:

    Passive relay output:

        The external power supply voltages 30VDC

The maximum load current is less than or equal to 0.2A

Passive collector output:

        The external power supply voltages 30VDC

The maximum load current is less than or equal to 60mA

Active output: high level over 20V The low level is less than or equal; 3V

The maximum output power 24VDC/30mA

The switching frequency is less than or equal to: 5kHz (collector output)

Dielectric strength: input / The output is more than 2000VAC ( 1min )

output / The power is greater than or equal to 2000VAC ( 1min )

          input / The power is greater than or equal to 1000VAC ( 1min )

Insulation resistance: input / output / The power is greater than or equal to 100M (omega 500VDC )

Remarks： One enter One A model, One , Three , Eleven , Twelve Don't pick feet up



For details please download:MDSC309E series switchisolator(output)

Tags： MDSC309E   switch quantity isolator (output type)
