Product introduction



MDSC308E series switch isolator Mounted as a guide rail, the base and the host can be separated from the plug, easy installation and maintenance. Series of products rich, can handle the current, voltage, thermal resistance, thermocouple, switch and other industrial products are widely signal. The application in building material, metallurgy, electric power and other industries, effectively restrain all kinds of interference signal.



function

The receiving switch signal from the scene, such as signal proximity switch, isolation and output. Optional One enter One A, Oneenter Two A, Two enter Two A.



Type specification

Product model	1 input code	2 input code	The output of the 1 code	The output of the 2 code
MDSC308E-	1: passive switch	1: passive switch	1: passive relay	1: passive relay
	2: active switch	2: active switch	2: passive collector	2: passive collector
	G: other signals	G: other signals	4: active output	4: active output
		0: input 2	G: other signals	G: other signals
				0: output 2



Product features:

The input and output power, the three party is completely isolated, strong anti-interference ability

High precision, high linearity, high stability

Modular design, small volume, low power consumption, suitable for intensive installation

Reasonable structure, easy plugging, installation, disassembly and maintenance is more convenient and simple





Technical indicators

The working power supply: 24VDC . 10%

Work    Consumption: less than or equal to 2W ( Two enter Two (a) passive output)

Less than or equal to 3W ( Two enter Two (a) active output)

Input signal:

Passive switch input (contact):

Short circuit current: 8mA

The open circuit voltage: 8V

The loop current is less than or equal to 1.2mA "Guan said"

The loop current is greater than or equal to 2.1mA Said ""

Active switch input:

Order negotiation technology index

Output signal:

    Passive relay output:

        Contact type: normally open

Contact capacity: 0.2A /30VDC

    Passive collector output:

        External power supply: less than or equal to 30VDC

The load current is less than or equal to: 60mA

Active output: high level over 20V The low level is less than or equal; 3V

The maximum output power 24VDC/30mA

The switching frequency is less than or equal to: 5kHz (collector output)

Less than or equal to 20Hz (relay output)

Dielectric strength: input / The output is more than 2000VAC ( 1min )

input / The power is greater than or equal to 2000VAC ( 1min )

output / The power is greater than or equal to 1000VAC ( 1min )

Insulation resistance: input / output / The power is greater than or equal to 100M (omega 500VDC )

Remarks： One enter One A model, One , Three , Eleven , Twelve Don't pick feet up; One enter Two A model, One , Three Don't pick feet up.



For details please download:MDSC308E series switchisolator
